Introduction
The AISR206 is a compact and lightweight AIS receiver specifically designed for integration with small and medium-sized UAVs. It is a dual-channel AIS receiver with a built-in low-noise amplifier (LNA), offering features such as small size, light weight, and low power consumption—making it ideal for UAV applications. The AISR206 is equipped with a 6-pin JST-GH output interface, with pin assignments compatible with the Pixhawk telemetry port, enabling easy connection to UAV flight controllers.
Features
● Compact size and lightweight, suitable for UAV integration
● Outputs standard AIVDM message format
● Supports AIS message types 1-27
● Supports dual AIS channels
● Highly configurable for various application scenarios
● Optional output of AIS signal strength
● Optional reception of “Long-Range AIS” signals
● Integrated 6-pin JST-GH interface for flight controller connection
Specifications
|
No.
|
Specification
|
|
1
|
Input Voltage
|
3.7V~5.5V (5V recommended)
|
|
2
|
Power Consumption
|
70mA
|
|
3
|
Reception Frequencies
|
161.975 MHz, 162.025 MHz
|
|
4
|
Data Format
|
AIVDM
|
|
5
|
AIS Channels
|
2
|
|
6
|
Sensitivity
|
-113dBm
|
|
7
|
Bandpass Filter Range
|
156.3~162.025MHz
|
|
8
|
Input Impedance
|
50Ω
|
|
9
|
Dimensions
|
56x48.6x24.7 mm (not including antenna connector)
|
|
10
|
Weight
|
75g
|
|
11
|
Antenna Connector
|
SMA
|
Interface
|
No.
|
Pin Name
|
Function
|
|
1
|
5V
|
5V Power Input
|
|
2
|
RXD
|
Serial RX Input
|
|
3
|
TXD
|
Serial TX Output
|
|
4
|
SCL
|
I2C Clock
|
|
5
|
SDA
|
I2C Data
|
|
6
|
GND
|
Ground
|
SERIAL Configuration:
|
No.
|
Name
|
Configuration
|
|
1
|
Baud Rate
|
38400
|
|
2
|
Data Bits
|
8
|
|
3
|
Parity
|
none
|
|
4
|
Stop Bits
|
1
|
Connecting to the Flight Controller
The AISR206 can be connected to a flight controller to transmit received AIS data to the flight control hardware. The ground control station software can then display the information sent from the AISR206.
Connection Method: Use the 6-pin JST-GH cable to connect the AISR206 to the flight controller. After the flight controller is connected to the ground control station, launch the ground station software (e.g., MissionPlanner). Configure the relevant parameters, and the AIS data from the AISR206 will be displayed. To begin, run MissionPlanner, select the newly added COM port in the upper right corner of the main interface, and click the Connect button to establish a connection with the computer.
PC Debugging
The AISR206 can be connected to a computer for local debugging via a 6-pin JST-GH to USB module.
Customization
All our products can be supplied tailored to your specific needs and customized with your brand and logo. We tailor designs, enclosures, features, and data formats to meet your specifications. Our OEM services empower you to launch unique products swiftly and risk-free.
