The ADSBS600 is a fully integrated ADS-B ground station system, designed for seamless installation with standard 19″ 2U rack inserts. Tailored for ground station sites requiring 19″ plug-and-play compatibility, the ADSBS600 offers an ideal solution. Featuring a rugged industrial-grade design, an advanced ADS-B decoder, and a high-performance data processor, the ADSBS600 ensures reliable and efficient reception, decoding, and distribution of aircraft ADS-B data.
Fully compliant with Mode-S and ADS-B standards—including ICAO Annex 10, ICAO Doc 9871, RTCA DO-260/A/B, ED-102/A/B, and ED-129/A/B, the ADSBS600 ensures regulatory adherence and seamless compatibility with industry requirements. Designed for efficiency and reliability, it offers low maintenance demands and minimal life cycle costs, delivering a cost-effective solution over its operational lifespan.
Operating on the 1090 MHz frequency and supporting Mode S Extended Squitter (1090ES), the ADSBS600 is also equipped with multilateration (MLAT) capabilities for high-precision aircraft tracking and surveillance. In addition, its fully remote operation functionality enables convenient monitoring and control from virtually any location, enhancing both operational flexibility and overall efficiency.
|
No. |
Specifications |
|
|---|---|---|
|
1 |
Frequency |
1090MHz |
|
2 |
Sensitivity |
≤ -99dBm |
|
3 |
Coverage |
> 420km(no interference, unobstructed) |
|
4 |
Data Format |
ADS-B raw messages / CSV plaintext / JSON plaintext track data |
|
5 |
Data Interface |
RJ45 network port |
|
6 |
Network Connection |
Static IP or DHCP |
|
7 |
Network Protocol |
TCP/UDP |
|
8 |
ADS-B Antenna Interface |
N female |
|
9 |
GPS Antenna Interface |
SMA female |
|
10 |
Power Supply |
220V |
|
11 |
Physical Size |
43*30*8.9 cm (not include antenna connectors and handle) |
·ADSBS600 supports multiple output message formats: CSV plaintext (decoded data, you can easily get longitude, latitude, altitude, speed, flight ID…), json (also decoded data), and DF raw messages.
·ADSBS600 can output data with GPS timestamp.
·ADSBS600 can be connected via network cables.
·ADSBS600 IP address can be configured for direct connection with a computer without the need for routers. However, ADSBS600 can also be configured to connect with a computer via routers, offering flexibility based on your setup preferences.
·ADSBS600 supports static IP address and DHCP.
·A single ADSBS600 unit can send ADS-B data to multiple clients simultaneously, enabling efficient data distribution across multiple devices or systems.
·ADSBS600 is standard 19″ 2U inserts for existing or new racks.
The default IP address of the ADSBS600 is 192.168.10.10. It must be connected to a computer via the network port, either directly or through a router.
Backend Login
After connecting the device, enter the device's IP address in the browser's address bar and press Enter. Then, input the device configuration management login credentials.
Configuration Interface Homepage
The homepage is divided into two main sections: the Menu Bar and the Status Bar.
Menu Bar: Includes options for Network Configuration, Data Interface Configuration, Time Service, GNSS Status, Clock Status, and Logout.
Status Bar: Displays the Service Status (indicating whether the device is receiving ADS-B signals), Network Status (showing the current network settings of the device), and System Operations (used for rebooting or shutting down the device).
The ADSBS600 can be connected to the display software adsbScope.
